How to Fix Whirlpool Refrigerator Error Er dF
Problem: Defrost system failure – excessive frost buildup detected or defrost cycle timeout

How to Fix Refrigerator Error
1. Unplug refrigerator and manually defrost evaporator coils using hair dryer (never sharp objects).
2. Remove rear wall panel in freezer to inspect evaporator for ice buildup.
3. Test defrost thermostat continuity when cold (<15°F) - should read 0 ohms. Warm to room temperature - should read infinite resistance.
4. Test defrost heater resistance (20-40 ohms) as described in Er dH procedure.
5. Inspect defrost drain tube for clogs causing water backup onto evaporator (clear with warm water and pipe cleaner).
6. Check evaporator fan operation – stalled fan causes poor airflow and excessive frosting.
7. If heater and thermostat test good but error persists, suspect failed defrost timer circuit on main control board.
8. Replace main control board W11035831 if all components test good.
9. After repair, monitor defrost cycle operation – should activate every 8-12 hours for 20-30 minutes.
10. Verify evaporator coils frost evenly during cooling cycle and completely defrost during defrost cycle.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Refrigerator Error Er CF
Problem: Control board fan failure – condenser fan not operating

How to Fix Refrigerator Error
1. Unplug refrigerator and pull unit away from wall to access rear compartment.
2. Remove rear access panel covering condenser fan and compressor area.
3. Locate condenser fan motor mounted near compressor (typically 120V AC motor with 3-4 blades).
4. Manually spin fan blade – should rotate freely without binding or grinding noise.
5. Disconnect fan wiring harness and measure resistance across motor terminals (should read 50-200 ohms depending on model).
6. Verify 120V AC reaches fan connector during compressor operation (use multimeter with refrigerator running).
7. Inspect fan blade for cracks or obstructions (pet hair, dust buildup on condenser coils).
8. Clean condenser coils thoroughly with coil brush and vacuum to restore airflow.
9. If motor resistance is infinite or fan doesn’t run with power applied, replace condenser fan motor WPW
10. If fan tests good but error persists, replace main control board W10890099 (failed fan driver circuit).
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Refrigerator Error Er IF
Problem: Ice compartment fan failure – freezer air circulation fan not operating

How to Fix Refrigerator Error
1. Unplug refrigerator and remove all food from freezer compartment.
2. Remove rear wall panel in freezer section to access evaporator fan assembly.
3. Locate evaporator fan motor mounted above or beside evaporator coils.
4. Manually spin fan blade – should rotate freely without binding (ice buildup may prevent movement).
5. Thaw any ice accumulation on fan blade and housing using hair dryer on low setting.
6. Disconnect fan wiring harness and measure resistance across motor terminals (should read 50-150 ohms).
7. Verify 12V DC (or 120V AC depending on model) reaches fan connector during cooling cycle.
8. Inspect fan motor bearings for excessive play or grinding noise when rotated.
9. If motor resistance is infinite or fan doesn’t run with power applied, replace evaporator fan motor WPW
10. After replacement, verify proper airflow from freezer vents and temperature stabilization within 2 hours.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Refrigerator Error Er IM
Problem: The ice maker is not working. The control board isn’t getting a signal from the ice maker motor or sensor. The entire ice maker assembly usually needs to be swapped out.

How to Fix Er IM Error
1. - UNPLUG refrigerator from electrical power.
  - Remove ice bin and locate ice maker assembly in freezer compartment.
  - Release mounting screws securing ice maker. Disconnect wiring harness connector.
  - Inspect harness and connector for frost buildup, corrosion, or bent pins. Clean with isopropyl alcohol and soft brush.
  - Test ice maker module continuity per service manual specifications using multimeter.
  - If module tests faulty or shows physical damage (cracked housing, burnt spots), replace assembly using OEM part W
  - Connect new harness securely. Align mounting tabs and secure with screws.
  - Reinstall ice bin. Restore power. Initiate ice maker test cycle per model instructions to verify harvest cycle and communication.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Refrigerator Error Er FF
Problem: Freezer fan failure – evaporator fan motor not operating

How to Fix Refrigerator Error
1. Unplug refrigerator and remove all food from freezer compartment.
2. Remove rear wall panel in freezer section to access evaporator fan assembly.
3. Locate evaporator fan motor mounted above evaporator coils.
4. Manually spin fan blade – should rotate freely without binding (ice buildup common cause).
5. Thaw ice accumulation on fan blade using hair dryer on low setting (never chip ice with tools).
6. Disconnect fan wiring harness and measure resistance across motor terminals (should read 50-150 ohms).
7. Verify correct voltage reaches fan connector during cooling cycle (12V DC or 120V AC depending on model).
8. Inspect fan motor bearings for excessive play or grinding noise when rotated by hand.
9. Check wiring harness for damage near evaporator where moisture causes corrosion.
10. If motor resistance is infinite or fan doesn’t run with power applied, replace evaporator fan motor WPW
11. After replacement, verify proper airflow from freezer vents.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Refrigerator Error Er ES
Problem: Evaporator sensor fault – temperature sensor on evaporator coil failed

How to Fix Refrigerator Error
1. Unplug refrigerator and remove all food from freezer compartment.
2. Remove rear wall panel in freezer to access evaporator assembly.
3. Locate evaporator temperature sensor (small white probe clipped to evaporator tubing near coils).
4. Disconnect sensor connector (typically 2-wire white connector).
5. Measure resistance at room temperature (77°F/25°C): should read 5kΩ ±5%.
6. Place sensor tip in ice water (32°F/0°C) – resistance should increase to approximately 15kΩ.
7. If resistance is infinite (open circuit) or zero (shorted), replace sensor WPW
8. Verify sensor clip is securely attached to evaporator tubing (loose mounting causes inaccurate readings).
9. Inspect wiring harness for damage near evaporator fan where vibration occurs.
10. After replacement, monitor defrost cycle operation – should activate when evaporator reaches proper temperature (-10°F to -20°F).
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Refrigerator Error Er 1C
Problem: Inverter compressor communication failure (on models with variable speed compressors)

How to Fix Refrigerator Error
1. Unplug refrigerator immediately – inverter failure can damage compressor windings.
2. Remove rear access panel to access inverter board (mounted near compressor).
3. Inspect inverter board for burnt components, especially near power transistors and capacitors.
4. Check all connectors between inverter and compressor for corrosion or loose seating.
5. Verify 120V AC power reaches inverter board during operation.
6. Measure DC bus voltageon inverter (should be 300-340V DC when operating).
7. Inspect compressor terminal connections for arcing or overheating damage.
8. If inverter board shows visible damage or burnt components, replace inverter assembly W
9. If inverter tests good but error persists, compressor windings may be shorted – requires professional diagnosis.
10. After inverter replacement, monitor compressor operation through multiple cycles verifying smooth speed transitions without error codes.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 29, 2026
How to Fix Whirlpool Refrigerator Error Er 2C
Problem: Inverter compressor overcurrent fault

How to Fix Refrigerator Error
1. Unplug refrigerator immediately to prevent compressor damage.
2. Remove rear access panel to access inverter board and compressor terminals.
3. Disconnect compressor wiring from inverter and measure winding resistance between terminals (should be balanced 3-8 ohms).
4. Check for short to ground by measuring resistance between each terminal and compressor shell (should be infinite).
5. Inspect condenser coils for excessive dirt restricting airflow causing compressor overheating.
6. Verify condenser fan operates properly during compressor run cycles.
7. Check refrigerant lines for proper insulation – missing insulation causes liquid floodback damaging compressor.
8. If winding resistance is unbalanced or shorted to ground, compressor has failed (requires sealed system repair).
9. If compressor tests good but error persists, replace inverter assembly W
10. After repair, monitor compressor current draw during startup (should not exceed 12 amps for more than 3 seconds).
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 29, 2026
How to Fix Whirlpool Refrigerator Error Er 3C
Problem: Inverter compressor overtemperature fault

How to Fix Refrigerator Error
1. Unplug refrigerator and allow compressor to cool for 30 minutes.
2. Remove rear access panel and inspect condenser coils for dust/debris buildup restricting airflow.
3. Clean condenser coils thoroughly with coil brush and vacuum cleaner.
4. Verify condenser fan operates continuously when compressor runs – replace fan motor if stalled.
5. Check ambient temperature around refrigerator – must not exceed 110°F (high ambient causes overheating).
6. Inspect compressor mounting pads for deterioration causing vibration-induced overheating.
7. Measure compressor discharge line temperature with infrared thermometer (should not exceed 225°F during operation).
8. If discharge line exceeds 250°F, suspect refrigerant overcharge or restricted condenser airflow.
9. If all external factors corrected but error persists, replace inverter assembly W11338877 (faulty temperature sensing circuit).
10. After repair, monitor compressor temperatures during extended run cycles in warm ambient conditions.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 29, 2026
How to Fix Whirlpool Refrigerator Error Er 4C
Problem: Inverter DC bus overvoltage fault

How to Fix Refrigerator Error
1. Unplug refrigerator immediately – overvoltage can destroy inverter components.
2. Measure household voltage at outlet – should be 110-125V AC (voltage >130V causes overvoltage faults).
3. If household voltage exceeds 125V, contact utility company to correct voltage regulation.
4. Remove rear access panel to access inverter board.
5. Inspect DC bus capacitors on inverter for bulging tops or leaking electrolyte.
6. Check for burnt components near DC bus circuitry on inverter board.
7. Verify compressor windings aren’t shorted causing regenerative voltage spikes (measure winding resistance).
8. If household voltage is normal and compressor tests good, inverter board has failed.
9. Replace inverter assembly W
10. After replacement, monitor DC bus voltage during operation using oscilloscope if available (should not exceed 380V DC).
