Whirlpool Washer error code
Whirlpool Washer Error DL
Unplug washer and inspect door gasket for obstructions preventing full closure.
Unplug washer and inspect door gasket for obstructions preventing full closure.
Try these first
Start here before buying a part or taking the appliance apart.
- 1Unplug washer and inspect door gasket for obstructions
Unplug washer and inspect door gasket for obstructions preventing full closure.
- 2Remove lower kick panel to access door lock
Remove lower kick panel to access door lock assembly.
- 3Manually press door strike against lock mechanism -
Manually press door strike against lock mechanism - should hear distinct click when engaged.
A quick explanation
What does DL mean?
Unplug washer and inspect door gasket for obstructions preventing full closure.
The answer you came for
How to fix Whirlpool washer error DL
Start with the safest checks and work from simple to technical.
- 1
Unplug washer and inspect door gasket for obstructions
Unplug washer and inspect door gasket for obstructions preventing full closure.
- 2
Remove lower kick panel to access door lock
Remove lower kick panel to access door lock assembly.
- 3
Manually press door strike against lock mechanism -
Manually press door strike against lock mechanism - should hear distinct click when engaged.
- 4
Disconnect lock wiring harness and measure resistance
Disconnect lock wiring harness and measure resistance: primary coil 300-600 ohms, secondary 1000-1500 ohms.
- 5
Verify 120V AC reaches lock during operation (test
Verify 120V AC reaches lock during operation (test at connector with door closed).
- 6
Inspect lock strike plate alignment - should engage
Inspect lock strike plate alignment - should engage smoothly without binding.
- 7
Check wiring harness between lock and control board
Check wiring harness between lock and control board for damage near door hinge area.
- 8
If lock receives power but won't engage, or
If lock receives power but won't engage, or resistance readings are infinite, replace door lock assembly WPW
- 9
After replacement, verify lock engages within 3 seconds
After replacement, verify lock engages within 3 seconds of cycle start and releases within 2 minutes after cycle completion.
- 10
Test all cycles to confirm consistent door locking
Test all cycles to confirm consistent door locking operation.
Read the additional checks from the current guide
How to Fix Washer Error Unplug washer and inspect door gasket for obstructions preventing full closure.Remove lower kick panel to access door lock assembly.Manually press door strike against lock mechanism - should hear distinct click when engaged.Disconnect lock wiring harness and measure resistance: primary coil 300-600 ohms, secondary 1000-1500 ohms.Verify 120V AC reaches lock during operation (test at connector with door closed).Inspect lock strike plate alignment - should engage smoothly without binding.Check wiring harness between lock and control board for damage near door hinge area.If lock receives power but won't engage, or resistance readings are infinite, replace door lock assembly WPWAfter replacement, verify lock engages within 3 seconds of cycle start and releases within 2 minutes after cycle completion.Test all cycles to confirm consistent door locking operation. As an Amazon Associate, we earn from qualifying purchases through links on this page.
Recommended part
Recommended part for this error code
Part listed in the current guide
OEM candidate: WPW10351854
Price noted in the current guide: $65
Why this part is shown: It is associated with Whirlpool Washer error DL in the current guide. The error code alone does not prove this part has failed.
Compatibility varies by model. Confirm that the Amazon listing includes your complete washer model number before ordering.
You can open the recommendation now. Check model compatibility on the Amazon page before purchasing.
Affiliate disclosure: qualifying purchases may earn this site a commission at no additional cost to you.Replacement options
Ready to replace your washer?
If repairing this washer no longer feels worthwhile, compare three replacement paths below.
Why shop your replacement on Amazon?
-
Fast, free delivery
Prime members can get fast, free delivery on eligible items.
-
Convenient delivery options
Select large appliances may offer scheduled or Room of Choice delivery.
-
Haul-away options
Haul-away may be available for select appliances and delivery areas.
-
Installation help
Installation or assembly may be available on select items.
Delivery and service options, fees, and availability vary by item, seller, and delivery ZIP code. Confirm available services at Amazon checkout.
Value
$0-$599
Budget-friendly washers in the $0-$599 range.
Shop Value Options on AmazonBest Overall
$600-$999
Balanced washers in the $600-$999 range.
Shop Best Overall Options on AmazonPremium
$1,000-$2,500
Higher-end washers in the $1,000-$2,500 range.
Shop Premium Options on AmazonMake the money decision
Repair or replace calculator
Use the age and total repair estimate to get a simple comparison. This is guidance, not a guarantee.
Safety first
Disconnect power before opening panels or touching internal parts.
When to stop
- Stop if you see burned wiring, melted connectors, water near electrical parts, or a gas smell.
- Do not perform live-voltage testing unless you are trained and equipped for it.
- Use the exact model manual or service information before replacing electronic controls.
