Category: Washer

  • How to Fix Amana Washer Error F5 E2

    How to Fix Amana Washer Error F5 E2

    Error Code: F5 E2 Difficulty: Moderate

    Problem: The door is not locking properly.

    How to Fix F5 E2 Error (Step-by-Step)

    1. Unplug the washer from its power source and confirm the error stays cleared during a full test cycle.
    2. Open the washer door and check for any obstructions on the door or the locking mechanism that could prevent a secure closure.
    3. If the path is clear, you will need to replace the door lock. Remove the top panel by unscrewing it from the back.
    4. Locate the door lock assembly (Part No. W11307244) on the front frame of the washer chassis.
    5. Unplug the electrical connector from the lock and remove the mounting screws.
    6. Fit the new door lock into place, secure it with the screws, and plug in the electrical connector.
    7. Re-secure the top panel, plug the washer in, and run a test cycle.
    8. Turn the appliance off, wait about 2 minutes, then turn it back on.

    Still Not Working?
    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.




  • How to Fix Amana Washer Error F5 E3

    How to Fix Amana Washer Error F5 E3

    Error Code: F5 E3 Difficulty: Moderate

    Problem: Lid Unlock Fault

    How to Fix F5 E3 Error (Step-by-Step)

    1. Disconnect the washer from the electrical outlet to prevent any electrical shock.
    2. Once the door is open, proceed to replace the faulty lock assembly (Part No. W11307244).
    3. Disconnect the wiring and remove the screws holding the old lock.
    4. Install the new lock assembly, reconnect the wiring, and reassemble the washer.
    5. Plug the washer back in and test the door lock function.
    6. Turn the appliance off, wait about 2 minutes, then turn it back on.
    7. Check for simple blockages (lint screen, drain path, or filter) and clean anything you find.

    Still Not Working?
    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.




  • How to Fix Amana Washer Error F5 E4

    How to Fix Amana Washer Error F5 E4

    Error Code: F5 E4 Difficulty: Easy

    Problem: Lid Not Opened

    How to Fix F5 E4 Error (Step-by-Step)

    1. Press the ‘Cancel’ or ‘Power’ button to clear the cycle.
    2. The code indicates the control did not see the lid opened after the last cycle.
    3. Lift the washer lid to its fully open position and confirm the error stays cleared during a full test cycle.
    4. Close the lid again, ensuring it clicks shut firmly and confirm the error stays cleared during a full test cycle.
    5. This action resets the lid switch sensor in the washer’s control unit.
    6. Select your desired cycle and press ‘Start’ to begin a new wash.
    7. Turn the appliance off, wait about 2 minutes, then turn it back on.

    Still Not Working?
    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.




  • How to Fix Amana Washer Error F7 E1

    How to Fix Amana Washer Error F7 E1

    Error Code: F7 E1 Difficulty: Hard

    Problem: Motor Speed Sensing Error

    How to Fix F7 E1 Error (Step-by-Step)

    1. Unplug the washer from the power outlet for safety and confirm the error stays cleared during a full test cycle.
    2. Turn off both hot and cold water supplies and confirm the error stays cleared during a full test cycle.
    3. Carefully tilt the washer forward, resting it securely against a wall or with assistance to access the bottom panel.
    4. Locate the shift actuator and the motor run capacitor. The actuator is a small motor with a lever, and the capacitor is a cylindrical component near the main drive motor.
    5. Disconnect the wire harnesses from both the old shift actuator and the capacitor. Remove the screws holding them in place.
    6. Install the new shift actuator (Part: WPW10006355) and motor run capacitor (Part: W10804665), securing them with their mounting screws.
    7. Reconnect the wire harnesses, carefully return the washer to its upright position, and restore power and water.
    8. Turn the appliance off, wait about 2 minutes, then turn it back on.

    Verified Compatible Alternatives:

    • W10804665 (Motor Run Capacitor)

    Still Not Working?
    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.




  • How to Fix Amana Washer Error F7 E5

    How to Fix Amana Washer Error F7 E5

    Error Code: F7 E5 Difficulty: Hard

    Problem: Shifter Fault

    How to Fix F7 E5 Error (Step-by-Step)

    1. Disconnect the washer from the electrical outlet and confirm the error stays cleared during a full test cycle.
    2. Shut off the water supply valves leading to the washer.
    3. Tilt the machine forward to access the components underneath. Ensure it is stable and will not fall.
    4. Locate the shift actuator (Part: WPW10006355). It is mounted to the side of the transmission.
    5. Unplug the electrical connector attached to the actuator. Use a screwdriver or socket to remove the mounting screws.
    6. Position the new shift actuator and secure it with the screws. Reconnect the electrical plug.
    7. Gently set the washer back down, plug it in, and turn the water back on to test the repair.
    8. Turn the appliance off, wait about 2 minutes, then turn it back on.

    Still Not Working?
    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.




  • How to Fix Amana Washer Error F7 E6

    How to Fix Amana Washer Error F7 E6

    Error Code: F7 E6 Difficulty: Hard

    Problem: Motor Fault

    How to Fix F7 E6 Error (Step-by-Step)

    1. Unplug the washer from the wall outlet and turn off the water faucets.
    2. Lean the washer forward to get to the bottom panel where the motor is located.
    3. Remove the drive belt by rotating the large pulley while walking the belt off.
    4. Disconnect the wire harnesses to the drive motor and the capacitor. Remove the bolts holding the motor in place and take out the old motor.
    5. Install the new drive motor (Part: WP21001950 or W10836348) and the new capacitor (Part: W10804665).
    6. Re-install the drive belt by starting it on the motor pulley and then stretching it over the large transmission pulley.
    7. Reconnect all wiring, return the washer to its standing position, and test a cycle.
    8. Turn the appliance off, wait about 2 minutes, then turn it back on.

    Verified Compatible Alternatives:

    • W10836348 (Drive Motor)
    • WP21001950 (Drive Motor)

    Still Not Working?
    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.




  • How to Fix Amana Washer Error F7 E7

    How to Fix Amana Washer Error F7 E7

    Error Code: F7 E7 Difficulty: Hard

    Problem: Motor Unable to Reach Target RPM

    How to Fix F7 E7 Error (Step-by-Step)

    1. Disconnect the washer from its power source to prevent electrical shock.
    2. Access the electronic control board by removing the top panel or the console, usually held by screws at the back or sides.
    3. Take a clear picture of the wire connections on the old board before disconnecting anything.
    4. Carefully unplug all the wire harnesses from the old control board. Note any locking tabs that need to be released.
    5. Remove the mounting screws that hold the control board in its housing and lift it out.
    6. Place the new control board (Part: W11170317 or W10785628) into the housing and secure it with the screws.
    7. Using your photo as a guide, reconnect all wire harnesses to the correct terminals on the new board, then reassemble the console and plug in the washer.
    8. Turn the appliance off, wait about 2 minutes, then turn it back on.

    Verified Compatible Alternatives:

    • W11170317 (Electronic Control Board)

    Still Not Working?
    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.




  • How to Fix Amana Washer Error F8 E1

    How to Fix Amana Washer Error F8 E1

    Error Code: F8 E1 Difficulty: Moderate

    Problem: Low Flow of Water

    How to Fix F8 E1 Error (Step-by-Step)

    1. Unplug the washer and turn off the hot and cold water supply lines.
    2. Place a towel behind the washer to catch any residual water and disconnect the water inlet hoses from the back of the machine.
    3. Remove the screws from the back panel to access the water inlet valve at the top.
    4. Disconnect the wire harnesses attached to the valve solenoids and confirm the error stays cleared during a full test cycle.
    5. Remove the screws holding the water inlet valve assembly in place and remove the old valve.
    6. Install the new water inlet valve (Part: W11220230, 205613, or W11210459) and secure it with its mounting screws.
    7. Reconnect the wire harnesses and water hoses, then turn the water on and check for leaks before plugging the washer back in.
    8. Turn the appliance off, wait about 2 minutes, then turn it back on.

    Verified Compatible Alternatives:

    • W11210459 (Water Inlet Valve)
    • W11220230 (Water Inlet Valve)

    Still Not Working?
    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.




  • How to Fix Amana Washer Error F8 E2

    How to Fix Amana Washer Error F8 E2

    Error Code: F8 E2 Difficulty: Easy

    Problem: Dispenser System Problem

    How to Fix F8 E2 Error (Step-by-Step)

    1. Open the dispenser drawer and press the release tab to remove it completely from the washer.
    2. Separate the different components of the drawer, such as the siphon cover and inserts.
    3. Thoroughly wash all parts of the dispenser drawer with warm, soapy water and a soft brush to remove any built-up detergent or fabric softener residue.
    4. Clean the inside of the dispenser housing on the washer itself, paying attention to the area above where residue can accumulate.
    5. Rinse all parts with clean water and dry them completely before reassembling the drawer.
    6. Slide the clean dispenser drawer back into the washer until it clicks into place.
    7. Run a rinse cycle to ensure everything is functioning correctly.
    8. Turn the appliance off, wait about 2 minutes, then turn it back on.

    Still Not Working?
    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.




  • How to Fix Amana Washer Error F9 E1

    How to Fix Amana Washer Error F9 E1

    Error Code: F9 E1 Difficulty: Moderate

    Problem: Long Drain Time

    How to Fix F9 E1 Error (Step-by-Step)

    1. Unplug the washer from power before starting the repair and confirm the error stays cleared during a full test cycle.
    2. Check the drain hose at the back of the machine to ensure it is not kinked, bent, or clogged.
    3. Disconnect the drain hose from the household drain pipe to check for obstructions at the connection point.
    4. If the hose is clear, you will need to access the drain pump at the bottom of the washer by tilting the machine forward.
    5. Place a shallow pan and towels under the pump to catch water, then disconnect the hoses from the pump by releasing the spring clamps.
    6. Disconnect the pump’s wire connector and remove the screws holding it to the washer base. Install the new drain pump (Part: W10536347).
    7. Reconnect hoses and wires, then carefully set the washer upright, restore power, and test the drain function.
    8. Turn the appliance off, wait about 2 minutes, then turn it back on.

    Still Not Working?
    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
