Samsung Washer error code

Samsung Washer Error 5E

Clear drain filter thoroughly as per nd procedure.

Clear drain filter thoroughly as per nd procedure.

UnknownStart with 5-15 minutes of safe checks
✅ WORTH FIXINGParts under $100
Samsung washer repair guide for error 5E
Error code5EWasher

Try these first

Start here before buying a part or taking the appliance apart.

  1. 1
    Clear drain filter thoroughly as per nd procedure

    Clear drain filter thoroughly as per nd procedure.

  2. 2
    Disconnect power for 10 minutes to reset PCB

    Disconnect power for 10 minutes to reset PCB memory.

  3. 3
    Inspect pump wiring harness at connector J4 on

    Inspect pump wiring harness at connector J4 on main PCB - look for burnt pins or moisture corrosion.

A quick explanation

What does 5E mean?

Clear drain filter thoroughly as per nd procedure.

The answer you came for

How to fix Samsung washer error 5E

Start with the safest checks and work from simple to technical.

  1. 1

    Clear drain filter thoroughly as per nd procedure

    Clear drain filter thoroughly as per nd procedure.

  2. 2

    Disconnect power for 10 minutes to reset PCB

    Disconnect power for 10 minutes to reset PCB memory.

  3. 3

    Inspect pump wiring harness at connector J4 on

    Inspect pump wiring harness at connector J4 on main PCB - look for burnt pins or moisture corrosion.

  4. 4

    Reconnect power and enter diagnostic mode

    Reconnect power and enter diagnostic mode: press Temp + Delay Start + Power simultaneously, then press Temp 4 times to activate drain pump.

  5. 5

    Listen for pump operation - if silent but

    Listen for pump operation - if silent but voltage present (measure 120V AC at connector during drain cycle), replace drain pump DC34-00008A.

  6. 6

    If no voltage at pump connector

    If no voltage at pump connector: check PCB relay RL4 continuity with multimeter (should read closed circuit when energized).

  7. 7

    Replace main PCB DC92-01543A if relay defective or

    Replace main PCB DC92-01543A if relay defective or traces burned near relay location.

  8. 8

    Restart the washer and confirm the 5E message

    Restart the washer and confirm the 5E message returns under the same condition instead of after a one-time interruption.

  9. 9

    Check the simple causes first

    Check the simple causes first: load balance, water supply, drain flow, door or lid closure, visible leaks, and power stability.

  10. 10

    Inspect accessible wiring connectors and moisture-prone areas before

    Inspect accessible wiring connectors and moisture-prone areas before assuming the control board has failed.

  11. 11

    Use the complete Samsung washer model number from

    Use the complete Samsung washer model number from the door, lid, or rear tag before matching any pump, valve, sensor, suspension, lock, or board category.

  12. 12

    If the 5E code points to a specific

    If the 5E code points to a specific system, test that system directly before ordering replacement parts.

Read the additional checks from the current guide

How to Fix 5E Error Clear drain filter thoroughly as per nd procedure.Disconnect power for 10 minutes to reset PCB memory.Inspect pump wiring harness at connector J4 on main PCB - look for burnt pins or moisture corrosion.Reconnect power and enter diagnostic mode: press Temp + Delay Start + Power simultaneously, then press Temp 4 times to activate drain pump.Listen for pump operation - if silent but voltage present (measure 120V AC at connector during drain cycle), replace drain pump DC34-00008A.If no voltage at pump connector: check PCB relay RL4 continuity with multimeter (should read closed circuit when energized).Replace main PCB DC92-01543A if relay defective or traces burned near relay location. Samsung Washer 5E Checks Before Replacing Parts Restart the washer and confirm the 5E message returns under the same condition instead of after a one-time interruption. Check the simple causes first: load balance, water supply, drain flow, door or lid closure, visible leaks, and power stability. Inspect accessible wiring connectors and moisture-prone areas before assuming the control board has failed. Use the complete Samsung washer model number from the door, lid, or rear tag before matching any pump, valve, sensor, suspension, lock, or board category. If the 5E code points to a specific system, test that system directly before ordering replacement parts. Recommended Parts to Check Samsung washer parts for 5E error Estimated part range: $25-$180 Confirm compatibility with your full Samsung washer model number before ordering. Check Price & Availability ->

If the code comes back

Do not keep replacing parts based only on the code. Repeat the safe checks above. If the fault remains, stop and arrange qualified service rather than ordering from the code alone.

Recommended part

Recommended part for this error code

No replacement part recommended for this code

The researched guidance for Samsung Washer error 5E points to user-action and diagnostic steps above rather than a mapped replacement part. We will not invent a part or send you to an unrelated product.

Replacement options

Ready to replace your washer?

If repairing this washer no longer feels worthwhile, compare three replacement paths below.

Why shop your replacement on Amazon?

  • Fast, free delivery

    Prime members can get fast, free delivery on eligible items.

  • Convenient delivery options

    Select large appliances may offer scheduled or Room of Choice delivery.

  • Haul-away options

    Haul-away may be available for select appliances and delivery areas.

  • Installation help

    Installation or assembly may be available on select items.

Delivery and service options, fees, and availability vary by item, seller, and delivery ZIP code. Confirm available services at Amazon checkout.

Affiliate disclosure: qualifying purchases may earn this site a commission at no additional cost to you.

Make the money decision

Repair or replace calculator

Use the age and total repair estimate to get a simple comparison. This is guidance, not a guarantee.

Safety first

Disconnect power before opening panels or touching internal parts.

When to stop
  • Stop if you see burned wiring, melted connectors, water near electrical parts, or a gas smell.
  • Do not perform live-voltage testing unless you are trained and equipped for it.
  • Use the exact model manual or service information before replacing electronic controls.
