  • How to Fix Kenmore Refrigerator Error Er IS

    How to Fix Kenmore Refrigerator Error Er IS

    Problem: Ice level sensor/optic eye failure in freezer door detecting ice bin full condition

    How to Fix Refrigerator Error

    1. UNPLUG refrigerator.
    2. Open freezer door and locate emitter/receiver sensors on opposite walls of ice chute (small red lenses).
    3. Clean lenses thoroughly with soft cloth and isopropyl alcohol.
    4. Check alignment – sensors must face each other directly without obstruction.
    5. Disconnect wiring harnesses and test continuity through sensor circuit.
    6. If sensors clean/aligned but error persists, replace both emitter and receiver assemblies (must replace as pair).
    7. Verify operation by placing hand between sensors – ice maker should stop when beam interrupted.

    Still Not Working?

    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.


  • How to Fix Kenmore Refrigerator Error SY EF

    How to Fix Kenmore Refrigerator Error SY EF

    Problem: System evaporator fault – evaporator fan motor failure or communication loss with main control board (253 series)

    How to Fix Refrigerator Error

    1. UNPLUG unit.
    2. Remove rear panel inside freezer compartment.
    3. Locate evaporator fan motor behind coils.
    4. Disconnect harness and test motor windings (should read 50-150 ohms).
    5. Manually spin fan blade – should rotate freely without ice obstruction.
    6. If motor good, inspect wiring harness between fan and main control board for damage.
    7. Check main control board connectors for corrosion/bent pins.
    8. If motor faulty, replace evaporator fan assembly.
    9. If wiring/board suspect, replace main control board (located in rear compressor compartment).
    10. After repair, verify fan runs continuously when doors closed.

    Still Not Working?

    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.


  • How to Fix Kenmore Refrigerator Error 5Y EF

    How to Fix Kenmore Refrigerator Error 5Y EF

    Problem: Temperature sensor fault causing evaporator fan circuit error (253 series variant)

    How to Fix Refrigerator Error

    1. UNPLUG refrigerator.
    2. Test BOTH freezer and refrigerator thermistors for proper resistance values (consult tech sheet for model-specific values).
    3. If either sensor out of spec, replace faulty thermistor.
    4. If sensors good, proceed to evaporator fan motor testing per SY EF procedure.
    5. Check voltage at fan motor connector when door closed (should read 12-14V DC).
    6. If voltage present but fan not running, replace fan motor.
    7. If no voltage, suspect main control board failure – replace board after confirming all sensors/fans test good.

    Still Not Working?

    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.


  • How to Fix Kenmore Refrigerator Error SY CE

    How to Fix Kenmore Refrigerator Error SY CE

    Problem: Communication error between main control board and user interface/display board

    How to Fix Refrigerator Error

    1. UNPLUG unit for 5 minutes to reset electronics.
    2. Restore power and check if error clears temporarily.
    3. If error returns, remove rear access panel to locate main control board (compressor compartment).
    4. Inspect all wire harness connections to board – unplug/replug each connector firmly.
    5. Check for burnt components or swollen capacitors on boards.
    6. Test continuity of communication wires between main board and display board (typically 4-6 conductor ribbon cable).
    7. If wiring intact but error persists, replace main control board first (more common failure point).
    8. If error remains after main board replacement, replace display/user interface board.

    Still Not Working?

    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.


  • How to Fix Kenmore Refrigerator Error F1

    How to Fix Kenmore Refrigerator Error F1

    Problem: Refrigerator compartment thermistor open circuit or out-of-range reading

    How to Fix Refrigerator Error

    1. UNPLUG refrigerator.
    2. Locate fresh food thermistor – typically behind rear wall panel near top air vent or in light assembly housing.
    3. Remove access panel and disconnect sensor connector.
    4. Measure resistance at room temperature (should be 5k-15k ohms depending on model).
    5. If reading OL (open) or wildly out of spec, replace thermistor.
    6. Route new sensor wire carefully avoiding door hinge pinch points.
    7. Secure sensor in original clip/location.
    8. Restore power and allow 4-6 hours for temperature stabilization before evaluating performance.

    Still Not Working?

    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.


  • How to Fix Kenmore Refrigerator Error F2

    How to Fix Kenmore Refrigerator Error F2

    Problem: Freezer compartment thermistor failure

    How to Fix Refrigerator Error

    1. UNPLUG unit.
    2. Remove evaporator cover panel inside freezer compartment.
    3. Locate freezer thermistor clipped to evaporator coil tubing (white probe with 2 wires).
    4. Disconnect connector and test resistance (5k-15k ohms at room temp).
    5. Replace if open/shorted or reading outside specification.
    6. IMPORTANT: Position new sensor in EXACT same location as original – even 1 inch difference causes temperature control issues.
    7. Secure with original clip or high-temp adhesive.
    8. Reassemble and verify freezer reaches 0°F within 4 hours of startup.

    Still Not Working?

    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.


  • How to Fix Kenmore Refrigerator Error F3

    How to Fix Kenmore Refrigerator Error F3

    Problem: Defrost system failure – heater or thermostat fault causing excessive frost buildup

    How to Fix Refrigerator Error

    1. UNPLUG refrigerator and initiate manual defrost (leave doors open 8-12 hours until all ice melts).
    2. Remove evaporator cover panel in freezer.
    3. Test defrost heater for continuity (should read 20-50 ohms).
    4. Test defrost thermostat when cold/frozen (should read closed/<1 ohm).
    5. Replace faulty component(s).
    6. Inspect wiring for burnt sections near heater connections.
    7. After repair, monitor for 3 defrost cycles (typically every 8-10 hours) to verify heater activates and melts frost completely each cycle.
    8. If frost returns within 48 hours, suspect adaptive defrost control board failure.

    Still Not Working?

    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.


  • How to Fix Kenmore Refrigerator Error F4

    How to Fix Kenmore Refrigerator Error F4

    Problem: Evaporator fan motor failure in fresh food compartment (dual evaporator models)

    How to Fix Refrigerator Error

    1. UNPLUG unit.
    2. Locate fresh food evaporator fan – typically behind rear wall panel in refrigerator section (not freezer).
    3. Remove access panel (4-6 screws).
    4. Disconnect wiring harness and test motor windings.
    5. Manually spin fan blade – check for ice obstruction or bearing failure.
    6. Replace motor assembly if faulty.
    7. Ensure fan blade orientation matches original (critical for proper airflow direction through diffuser).
    8. Verify operation by listening for continuous fan operation when doors closed – should hear gentle airflow from rear vents.

    Still Not Working?

    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.


  • How to Fix Kenmore Refrigerator Error F5

    How to Fix Kenmore Refrigerator Error F5

    Problem: Water inlet valve failure preventing water flow to ice maker/dispenser

    How to Fix Refrigerator Error

    1. SHUT OFF water supply valve and UNPLUG refrigerator.
    2. Remove rear lower access panel.
    3. Locate water inlet valve (solenoid assembly with 1/4″ water line input and 2 outputs).
    4. Disconnect electrical connectors and water lines (have towels ready).
    5. Remove mounting screws and extract valve assembly.
    6. Test solenoid coils for continuity (should read 300-500 ohms each).
    7. Replace entire valve assembly if either coil open or leaking.
    8. Reconnect water lines hand-tight plus 1/4 turn, open supply valve slowly, check for leaks before restoring power.
    9. Test dispenser and ice maker operation.

    Still Not Working?

    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.


  • How to Fix Kenmore Refrigerator Error F6

    How to Fix Kenmore Refrigerator Error F6

    Problem: Dispenser motor or auger drive failure preventing ice dispensing

    How to Fix Refrigerator Error

    1. UNPLUG unit.
    2. Remove ice bin and locate dispenser motor behind rear wall of freezer door.
    3. Disconnect wiring harness and remove mounting screws.
    4. Inspect drive coupling for stripped gears or broken shaft.
    5. Manually rotate auger shaft to check for ice jams or foreign objects.
    6. If motor doesn’t rotate when powered (test with multimeter) or gears stripped, replace motor assembly.
    7. Clean ice bin thoroughly before reinstalling to prevent re-jamming.
    8. Verify operation by requesting cubed/crushed ice – should hear motor engage and ice dispense within 3 seconds.

    Still Not Working?

    If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
