How to Fix Amana Refrigerator Error D9 ILLUMINATED

Written by

⚠️ Safety Warning: Appliance repair involves electricity, gas, and moving parts. Always disconnect power before working on any appliance.

Error Code: D9 ILLUMINATED Difficulty: Hard

Problem: Defrost sensor issue.

⚖️ Repair Decision

✅ WORTH FIXING

Parts under $100

How to Fix D9 ILLUMINATED Error (Step-by-Step)

Unplug the refrigerator from the wall outlet to ensure safety.
Empty the freezer compartment of all food and shelves and confirm the error stays cleared during a full test cycle.
Locate and remove the screws holding the interior back panel of the freezer.
Carefully detach the panel to expose the evaporator coils and the old defrost sensor, which is a small probe clipped to the coils.
Disconnect the wire harness of the old sensor and unclip it from the coil.
Clip the new sensor (Part WPW10384183) in the exact same position and reconnect its wire harness.
Reinstall the back panel, shelves, and plug the refrigerator back in.
Turn the appliance off, wait about 2 minutes, then turn it back on.

OEM Part #: WPW10384183

Estimated Market Price: $20-$60

Still Not Working?
If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
