Samsung Dishwasher error code

Samsung Dishwasher Error LE

Unplug dishwasher and remove lower access panel.

Unplug dishwasher and remove lower access panel.

HardStart with 5-15 minutes of safe checks
⚠️ CHECK WARRANTY / AGE$100 - $250 Range
Samsung dishwasher repair guide for error LE
Error codeLEDishwasher

Try these first

Start here before buying a part or taking the appliance apart.

  1. 1
    Unplug dishwasher and remove lower access panel

    Unplug dishwasher and remove lower access panel.

  2. 2
    Manually rotate wash impeller from pump housing access

    Manually rotate wash impeller from pump housing access. Listen for grinding or feel for resistance.

  3. 3
    Disconnect motor wiring harness from main board

    Disconnect motor wiring harness from main board. Label connections.

A quick explanation

What does LE mean?

Unplug dishwasher and remove lower access panel.

The answer you came for

How to fix Samsung dishwasher error LE

Start with the safest checks and work from simple to technical.

  1. 1

    Unplug dishwasher and remove lower access panel

    Unplug dishwasher and remove lower access panel.

  2. 2

    Manually rotate wash impeller from pump housing access

    Manually rotate wash impeller from pump housing access. Listen for grinding or feel for resistance.

  3. 3

    Disconnect motor wiring harness from main board

    Disconnect motor wiring harness from main board. Label connections.

  4. 4

    Test motor windings resistance between terminals (U-V, V-W,

    Test motor windings resistance between terminals (U-V, V-W, W-U). Reading must be balanced (3-8Ω).

  5. 5

    Test hall sensor resistance within motor assembly per

    Test hall sensor resistance within motor assembly per wiring diagram (typically

  6. 6

    Inspect impeller area for foreign objects (utensils, broken

    Inspect impeller area for foreign objects (utensils, broken glass). Remove obstructions carefully.

  7. 7

    If motor binds mechanically or electrical tests fail

    If motor binds mechanically or electrical tests fail: remove mounting bolts securing motor.

  8. 8

    Extract old wash motor assembly

    Extract old wash motor assembly. Clean mounting surface thoroughly.

  9. 9

    Install new motor assembly using OEM part DD31-00008A

    Install new motor assembly using OEM part DD31-00008A. Torque mounting bolts to 18 in-lbs.

  10. 10

    Reconnect wiring harness

    Reconnect wiring harness. Restore power. Run motor diagnostic test to verify smooth acceleration and rotation.

Read the additional checks from the current guide

How to Fix Dishwasher Error Unplug dishwasher and remove lower access panel.Manually rotate wash impeller from pump housing access. Listen for grinding or feel for resistance.Disconnect motor wiring harness from main board. Label connections.Test motor windings resistance between terminals (U-V, V-W, W-U). Reading must be balanced (3-8Ω).Test hall sensor resistance within motor assembly per wiring diagram (typically5-5kΩ).Inspect impeller area for foreign objects (utensils, broken glass). Remove obstructions carefully.If motor binds mechanically or electrical tests fail: remove mounting bolts securing motor.Extract old wash motor assembly. Clean mounting surface thoroughly.Install new motor assembly using OEM part DD31-00008A. Torque mounting bolts to 18 in-lbs.Reconnect wiring harness. Restore power. Run motor diagnostic test to verify smooth acceleration and rotation.

If the code comes back

Do not keep replacing parts based only on the code. Repeat the safe checks above. If the fault remains, stop and arrange qualified service rather than ordering from the code alone.

Recommended part

Recommended part for this error code

Part listed in the current guide

OEM candidate: DD31-00008A

Price noted in the current guide: $112

Why this part is shown: It is associated with Samsung Dishwasher error LE in the current guide. The error code alone does not prove this part has failed.

Compatibility varies by model. Confirm that the Amazon listing includes your complete dishwasher model number before ordering.

Amazon part link View recommended part on Amazon

You can open the recommendation now. Check model compatibility on the Amazon page before purchasing.

Affiliate disclosure: qualifying purchases may earn this site a commission at no additional cost to you.

Replacement options

Ready to replace your dishwasher?

If repairing this dishwasher no longer feels worthwhile, compare three replacement paths below.

Why shop your replacement on Amazon?

  • Fast, free delivery

    Prime members can get fast, free delivery on eligible items.

  • Convenient delivery options

    Select large appliances may offer scheduled or Room of Choice delivery.

  • Haul-away options

    Haul-away may be available for select appliances and delivery areas.

  • Installation help

    Installation or assembly may be available on select items.

Delivery and service options, fees, and availability vary by item, seller, and delivery ZIP code. Confirm available services at Amazon checkout.

Affiliate disclosure: qualifying purchases may earn this site a commission at no additional cost to you.

Make the money decision

Repair or replace calculator

Use the age and total repair estimate to get a simple comparison. This is guidance, not a guarantee.

Safety first

Disconnect power before opening panels or touching internal parts.

When to stop
  • Stop if you see burned wiring, melted connectors, water near electrical parts, or a gas smell.
  • Do not perform live-voltage testing unless you are trained and equipped for it.
  • Use the exact model manual or service information before replacing electronic controls.
