⚠️ Safety Warning: Appliance repair involves electricity, gas, and moving parts. Always disconnect power before working on any appliance.
Error Code: Dishwasher Difficulty: Hard
Problem: Wash motor failure; seized bearings, winding fault, or hall sensor malfunction
How to Fix Dishwasher Error
- Unplug dishwasher and remove lower access panel.
- Manually rotate wash impeller from underneath (accessible through pump housing). Should turn smoothly with no grinding.
- Disconnect motor wiring harness from main board. Label all connections.
- Test motor windings resistance between terminals per service manual (typically balanced 3-8Ω readings).
- Test hall sensor resistance within motor assembly (refer to wiring diagram; typically
- 5-
- 5kΩ).
- Inspect motor area for foreign objects jamming impeller. Remove obstructions carefully.
- If motor binds mechanically or electrical tests fail: replace entire wash motor assembly using OEM part DD31-00008A.
- Remove mounting bolts, extract old motor, clean mounting surface thoroughly.
- Install new motor assembly. Torque mounting bolts to 18 in-lbs in crisscross pattern.
- Reconnect wiring harness. Restore power. Run motor diagnostic test to verify smooth operation and correct rotation direction.
Recommended Replacement Part
Still Not Working?
If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
