⚠️ Safety Warning: Appliance repair involves electricity, gas, and moving parts. Always disconnect power before working on any appliance.
Error Code: Dishwasher Difficulty: Hard
Problem: Flash code 5: Wash motor fault; seized bearings or electrical failure (non-display models)
How to Fix Dishwasher Error
- Unplug dishwasher and remove lower access panel.
- Manually rotate wash impeller from pump housing access. Should turn smoothly with no grinding.
- Disconnect motor wiring harness from main board. Label connections.
- Test motor windings resistance between terminals (U-V, V-W, W-U). Readings must be balanced (3-8Ω).
- Test hall sensor resistance within motor assembly per wiring diagram (typically
- 5-
- 5kΩ).
- Inspect impeller area for foreign objects jamming rotation. Remove obstructions carefully.
- If motor binds mechanically or electrical tests fail: remove mounting bolts securing motor.
- Extract old wash motor assembly. Clean mounting surface thoroughly.
- Install new motor assembly using OEM part DD31-00008A. Torque mounting bolts to 18 in-lbs.
- Reconnect wiring harness. Restore power. Run motor diagnostic test to verify smooth operation and correct rotation direction.
Recommended Replacement Part
Still Not Working?
If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
