Category: Whirlpool

How to Fix Whirlpool Washer Error F4E1
Problem: Heater element failure – open circuit or short detected

How to Fix Washer Error
1. Unplug washer and turn off water supply.
2. Remove lower front panel to access heater element mounted on outer tub.
3. Disconnect wiring harness from heater terminals.
4. Measure resistance across heater terminals with multimeter (should read 15-25 ohms).
5. If resistance is infinite (open circuit), element has failed internally.
6. If resistance is zero (shorted to ground), element has failed and may have damaged control board.
7. Inspect heater sheath for cracks, corrosion, or mineral buildup causing premature failure.
8. Check wiring harness for melted insulation near heat source.
9. Replace heating element assembly W10247593 – requires draining tub and removing mounting bolts.
10. After replacement, run hot water cycle and verify temperature reaches 120°F within 15 minutes of fill completion.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Washer Error F6E4
Problem: Leak detection – water detected in base pan activating float switch

How to Fix Washer Error
1. UNPLUG WASHER IMMEDIATELY and turn off water supply valves.
2. Tilt washer backward 45 degrees using wood blocks under front feet to access base pan.
3. Remove 3 screws securing base pan and lower carefully – expect standing water.
4. Dry base pan completely with towels and shop vacuum.
5. Locate source of leak: inspect inlet valve connections, drain pump seals, tub gasket, and hoses.
6. Common culprits: cracked drain pump housing, loose hose clamp, torn tub seal, or split inlet hose.
7. Run washer briefly with water supply on to observe leak source (use flashlight and mirror).
8. Replace leaking component: tub seal W10837740, drain hose WPW10351854, or inlet valve W
9. Verify float switch resets after pan is completely dry (should show open circuit when dry).
10. Reinstall base pan and test washer through complete cycle monitoring for leaks every 5 minutes.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Washer Error F81
Problem: Lid lock failure – lid not locking properly (Cabrio top-load models)

How to Fix Washer Error
1. Unplug washer and verify lid closes fully without obstruction.
2. Remove top panel to access lid lock assembly mounted under main top.
3. Manually operate lock mechanism – should move smoothly between locked/unlocked positions.
4. Disconnect lock wiring harness and measure resistance across coils (primary 300-600 ohms, secondary 1000-1500 ohms).
5. Verify 120V AC reaches lock during operation (test at connector with lid closed).
6. Inspect lock strike plate alignment on lid – should engage smoothly without binding.
7. Check wiring harness between lock and control board for damage near hinge area.
8. If lock mechanism binds mechanically, lubricate pivot points with silicone grease.
9. If electrical tests fail or mechanism is damaged, replace lid lock assembly WPW
10. After replacement, verify lock engages within 3 seconds of cycle start and washer won’t operate with lid open.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Washer Error drn
Problem: Drain system fault – water not draining within expected time

How to Fix Washer Error
1. Unplug washer and prepare for water drainage.
2. Remove 3 torx screws securing lower front panel.
3. Place large towel underneath pump access area.
4. Slowly unscrew drain pump filter cap counterclockwise (expect 1-2 cups residual water).
5. Remove all debris from filter basket and pump housing including coins, hairpins, and bra wires.
6. Manually rotate impeller with finger – must spin freely 360° without binding or grinding noise.
7. Check drain hose routing: maximum height 96 inches above floor, no sharp bends, and not inserted >
8. 5 inches into standpipe.
9. Disconnect drain hose from standpipe and inspect interior for clogs using flashlight.
10. If impeller is damaged, pump makes grinding noise, or doesn’t run during drain cycle, replace drain pump W
11. After repair, run diagnostic drain test cycle verifying complete drainage within 4 minutes with no error codes.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Refrigerator Error PF
Problem: Power failure detected during operation

How to Fix Refrigerator Error
1. Verify household circuit breaker hasn’t tripped – reset if necessary.
2. Check GFCI outlet (if applicable) hasn’t tripped – press reset button.
3. Inspect power cord for damage or loose connection at wall outlet.
4. Plug refrigerator directly into wall outlet (remove extension cords).
5. Verify outlet provides stable 120V AC using multimeter (voltage sags can trigger PF).
6. Press CANCEL button to clear display if error persists after power restoration.
7. If PF occurs repeatedly without actual power loss, suspect loose neutral connection in house wiring – contact electrician.
8. Check main control board power terminal connections for looseness (requires removing rear access panel).
9. If PF occurs during compressor startup, suspect weak household circuit unable to handle inrush current – dedicated 15-20 amp circuit recommended.
10. Monitor voltage at outlet during compressor startup using recording multimeter to detect sags below 105V.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Refrigerator Error Er CE
Problem: Communication error between user interface and main control board

How to Fix Refrigerator Error
1. Unplug refrigerator for 5 minutes to reset communication bus.
2. Remove rear access panel at top of cabinet to access main control board.
3. Locate 8-wire harness connecting main control board to user interface/display.
4. Disconnect and reconnect harness at both ends, inspecting for bent pins or corrosion.
5. Check harness routing for pinch points between cabinet panels or near sharp metal edges.
6. Verify continuity on all 8 wires between connectors (no opens or shorts to ground).
7. Inspect both boards for moisture damage or burnt components near communication ports.
8. If harness tests good but error persists, replace user interface board first (less expensive component).
9. If Er CE returns after interface replacement, replace main control board W
10. After repair, enter diagnostic mode (press and hold WATER FILTER + FAST COOL for 3 seconds) and verify all sensor readings display correctly.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Refrigerator Error Er rS
Problem: Refrigerator compartment temperature sensor fault – out of range reading

How to Fix Refrigerator Error
1. Unplug refrigerator and remove all food from fresh food compartment.
2. Locate temperature sensor behind rear wall panel in refrigerator section (typically near top center).
3. Remove shelves and unscrew rear wall panel to access sensor wiring harness.
4. Disconnect sensor connector and measure resistance with multimeter at room temperature (77°F/25°C): should read 5kΩ ±5%.
5. Place sensor in glass of ice water (32°F/0°C) – resistance should increase to approximately 15kΩ.
6. Place sensor in warm water (100°F/38°C) – resistance should decrease to approximately
7. 5kΩ.
8. If resistance readings are infinite, zero, or don’t change with temperature, replace sensor WPW
9. Inspect wiring harness between sensor and control board for damage, rodent chewing, or pinched wires near hinge areas.
10. Verify connector pins aren’t corroded or bent.
11. After replacement, reinstall panel and verify temperature display stabilizes within 1 hour of operation.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Refrigerator Error Er E2
Problem: EEPROM checksum error on main control board

How to Fix Refrigerator Error
1. Unplug refrigerator for 10 minutes to fully discharge board capacitors.
2. Remove rear access panel at top of cabinet to access main control board.
3. Inspect board for visible damage: burnt components, bulging capacitors, or moisture corrosion.
4. Check all wire harness connections for proper seating and corrosion – reseat firmly.
5. Verify 120V AC power supply to board is stable (no voltage sags during compressor startup).
6. If board appears physically intact but error persists after power cycle, EEPROM corruption has occurred.
7. Main control board must be replaced – EEPROM cannot be reprogrammed in field service.
8. Install new control board W11035831 and secure all mounting screws to prevent vibration damage.
9. After installation, enter diagnostic mode and run all system tests to verify proper operation.
10. Note: Power surges often cause this failure – recommend installing whole-house surge protector.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Refrigerator Error Er FS
Problem: Freezer compartment temperature sensor fault – out of range reading

How to Fix Refrigerator Error
1. Unplug refrigerator and remove all frozen food from freezer compartment.
2. Locate temperature sensor behind rear wall panel in freezer section (typically near evaporator coils).
3. Remove shelves/baskets and unscrew rear wall panel to access evaporator assembly.
4. Disconnect sensor connector (usually white 2-wire connector near evaporator coils).
5. Measure resistance with multimeter at freezer temperature (0°F/-18°C): should read approximately 25kΩ.
6. Warm sensor in hand to 77°F/25°C – resistance should decrease to approximately 5kΩ.
7. If resistance is infinite (open circuit) or zero (shorted), replace sensor WPW
8. Inspect sensor mounting clip – must be securely attached to evaporator tubing (loose mounting causes False readings).
9. Check wiring harness for damage near evaporator fan where vibration occurs.
10. After replacement, verify freezer temperature stabilizes at 0°F within 4 hours of operation.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
How to Fix Whirlpool Refrigerator Error Er dH
Problem: Defrost heater failure – open circuit detected during defrost cycle

How to Fix Refrigerator Error
1. Unplug refrigerator and remove all food from freezer compartment.
2. Remove rear wall panel in freezer to access evaporator assembly and defrost components.
3. Locate defrost heater mounted beneath evaporator coils (aluminum tube with wire leads).
4. Disconnect heater wiring harness connector.
5. Measure resistance across heater terminals with multimeter (should read 20-40 ohms).
6. If resistance is infinite (open circuit), heater has failed.
7. Inspect heater tube for visible cracks, corrosion, or burnt spots indicating failure.
8. Also test defrost thermostat (bi-metal switch mounted on evaporator) – should show continuity when cold (<15°F), open when warm (>50°F).
9. Replace failed component: defrost heater WPW10577402 or defrost thermostat WPW
10. After replacement, initiate manual defrost cycle (enter diagnostic mode, select test
11. and verify heater activates for 20-30 minutes melting frost completely.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 30, 2026
