Category: Whirlpool

How to Fix Whirlpool Washer Error F22
Problem: Door/lid lock failure – lock mechanism not engaging or sensing circuit fault

How to Fix Washer Error
1. Unplug washer and attempt manual door/lid release per model-specific procedure (usually pull tab near lock).
2. Remove top panel (top-load) or lower kick panel (front-load) to access lock assembly.
3. Inspect lock mechanism for physical obstructions preventing engagement.
4. Disconnect lock wiring harness and measure resistance: primary coil should read 300-600 ohms, secondary 1000-1500 ohms.
5. Check lock strike plate alignment – should engage smoothly without binding.
6. Verify 120V AC reaches lock during operation (test at connector with door closed).
7. Inspect wiring harness between lock and control board for damage near hinge areas.
8. If lock tests electrically good but won’t engage, replace door lock assembly WPW
9. If lock receives no power or error persists after replacement, replace main control board W
10. After repair, verify lock engages within 3 seconds of cycle start and releases within 2 minutes after cycle completion.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
February 1, 2026
How to Fix Whirlpool Washer Error F28
Problem: Communication error between main control board (CCU) and user interface board

How to Fix Washer Error
1. Unplug washer for 2 minutes to reset communication bus.
2. Remove top panel to access main control board (CCU) connections.
3. Locate ribbon cable or multi-wire harness connecting CCU to user interface/display board.
4. Disconnect and reconnect both ends of harness, inspecting for bent pins or corrosion.
5. Check harness routing for pinch points between cabinet panels.
6. Verify display board receives 5V DC from CCU (test at connector pins).
7. Inspect display board for moisture damage or burnt components near communication IC.
8. If harness tests good (continuity on all pins) but error persists, replace user interface board first (less expensive).
9. If F28 returns after interface replacement, replace main control board W
10. After repair, verify all display functions and button responses operate correctly through diagnostic mode.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
February 1, 2026
How to Fix Whirlpool Washer Error F30
Problem: Dispenser system error – actuator failure or linkage binding

How to Fix Washer Error
1. Unplug washer and remove dispenser drawer completely.
2. Clean all comparments thoroughly with warm water to remove detergent residue buildup.
3. Inspect dispenser housing for cracks or warping that could bind mechanism.
4. Remove top panel to access dispenser actuator motor mounted above dispenser.
5. Manually rotate actuator cam to verify smooth operation through full cycle.
6. Disconnect actuator wiring harness and measure resistance (should be 1500-2500 ohms).
7. Check for 120V AC at actuator connector during dispenser cycle using multimeter.
8. Inspect mechanical linkage between actuator and dispenser valves for binding or disconnection.
9. If actuator doesn’t move or resistance is infinite, replace dispenser actuator assembly W
10. Reassemble and run diagnostic dispenser test cycle verifying proper compartment sequencing.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
February 1, 2026
How to Fix Whirlpool Washer Error F32
Problem: Pressure switch failure – water level detection circuit fault

How to Fix Washer Error
1. Unplug washer and remove top panel to access pressure switch (mounted on right side wall).
2. Disconnect electrical connector and pressure hose from switch.
3. With hose disconnected, multimeter should show NO continuity across switch terminals.
4. Gently blow into pressure hose while monitoring continuity – switch should close at approximately
5. 5 PSI.
6. Check pressure hose for cracks, kinks, or water accumulation (replace hose WPW10351854 if damaged).
7. Verify hose connection at air dome on tub is secure and not clogged with detergent residue.
8. If switch doesn’t change state when blowing, replace pressure switch W
9. If switch tests good but error persists, check wiring harness continuity between switch and control board.
10. If harness tests good, replace main control board W
11. After repair, run diagnostic cycle verifying correct water level detection at multiple fill stages.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
February 1, 2026
How to Fix Whirlpool Washer Error F5E1
Problem: Door switch/latch failure – door not detected as closed

How to Fix Washer Error
1. Unplug washer and inspect door strike plate alignment on cabinet.
2. Remove lower kick panel (front-load) or top panel (top-load) to access door switch assembly.
3. Manually press door switch plunger – should click positively and show continuity change on multimeter.
4. Check switch mounting screws for looseness causing misalignment.
5. Inspect wiring harness at switch connector for corrosion or broken wires near hinge area.
6. Measure resistance across switch terminals: open when door open, closed (0 ohms) when door closed.
7. Verify door glass isn’t cracked causing improper closure force.
8. If switch doesn’t change state or shows intermittent continuity, replace door switch/latch assembly WPW
9. After replacement, verify door locks within 3 seconds of cycle start and washer won’t operate with door ajar.
10. Test all cycles to confirm consistent door detection.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
February 1, 2026
How to Fix Whirlpool Washer Error F5E2
Problem: Door lock failure – lock mechanism won’t engage or release

How to Fix Washer Error
1. Unplug washer and attempt manual door release using emergency pull tab (located behind lower kick panel).
2. Remove kick panel to access door lock assembly mounted on door frame.
3. Inspect lock hook for physical damage or debris preventing engagement.
4. Disconnect lock wiring harness and measure resistance: primary coil 300-600 ohms, secondary 1000-1500 ohms.
5. Check lock strike plate alignment – should engage smoothly without binding when door closes.
6. Verify 120V AC reaches lock during operation (test at connector with door closed).
7. Inspect wiring harness between lock and control board for damage near door hinge.
8. If lock receives power but won’t engage, or resistance readings are infinite, replace door lock assembly WPW
9. After replacement, verify lock engages within 3 seconds of cycle start and releases within 2 minutes after cycle completion.
10. Test operation through multiple cycles to confirm reliable locking/unlocking.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
February 1, 2026
How to Fix Whirlpool Washer Error F5E3
Problem: Door unlock failure – lock mechanism stuck in locked position

How to Fix Washer Error
1. Unplug washer immediately to prevent lock coil overheating.
2. Access emergency door release tab behind lower kick panel – pull firmly downward to manually unlock door.
3. Remove kick panel to inspect door lock assembly.
4. Check for foreign objects jamming lock mechanism (coins, buttons wedged in strike area).
5. Disconnect lock wiring harness and manually cycle lock plunger to verify mechanical freedom.
6. Measure resistance across lock coils – infinite resistance indicates open coil requiring replacement.
7. Inspect lock mounting screws for over-tightening causing binding.
8. Verify door alignment isn’t forcing excessive pressure on lock mechanism.
9. If mechanical operation is smooth but lock won’t release electrically, replace door lock assembly WPW
10. After replacement, verify lock releases within 120 seconds after cycle completion and doesn’t overheat during operation.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
February 1, 2026
How to Fix Whirlpool Washer Error F5E4
Problem: Door lock solenoid fault – excessive current draw detected

How to Fix Washer Error
1. Unplug washer immediately – excessive current can damage control board.
2. Remove lower kick panel to access door lock assembly.
3. Disconnect lock wiring harness and measure resistance across solenoid coils.
4. Primary coil should read 300-600 ohms; secondary 1000-1500 ohms. Readings below 200 ohms indicate shorted coil.
5. Inspect lock mechanism for binding that could cause solenoid to stall and overheat.
6. Check lock strike plate alignment – misalignment forces solenoid to work harder.
7. Verify wiring harness isn’t shorted to ground (measure resistance between each wire and chassis ground – should be infinite).
8. If solenoid resistance is low or lock mechanism binds, replace door lock assembly WPW
9. After replacement, monitor lock operation through 3 cycles verifying no excessive heat buildup at lock.
10. If error returns with new lock, suspect main control board shorted driver circuit requiring CCU replacement.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
February 1, 2026
How to Fix Whirlpool Washer Error F6E1
Problem: Communication error between ACU (analog control unit) and CCU (central control unit)

How to Fix Washer Error
1. Unplug washer for 5 minutes to reset communication bus.
2. Remove top panel to access main control board (CCU) connections.
3. Locate multi-wire harness connecting CCU to ACU (typically 8-12 wires in gray connector).
4. Disconnect and reconnect harness at both ends, inspecting for bent pins or corrosion.
5. Check harness routing for pinch points between tub support and cabinet.
6. Verify continuity on all pins between CCU and ACU connectors (no opens or shorts to ground).
7. Inspect both boards for moisture damage or burnt components near communication ports.
8. If harness tests good but error persists, replace ACU board first (less expensive component).
9. If F6E1 returns after ACU replacement, replace main control board (CCU) W
10. After repair, enter diagnostic mode and verify all sensor readings display correctly on interface.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 31, 2026
How to Fix Whirlpool Washer Error F7E1
Problem: Motor speed sensing error – motor unable to achieve required RPM for selected cycle

How to Fix Washer Error
1. Unplug washer and remove rear access panel.
2. Inspect drive system: belt condition, pulley alignment, and tub bearing smoothness.
3. Manually rotate tub – should spin freely without grinding or excessive resistance.
4. Check motor speed sensor (Hall effect) gap to rotor magnet (
5. 5-
6. 5mm clearance required).
7. Disconnect sensor connector and measure resistance (should be 1000-2000 ohms).
8. Spin motor shaft while monitoring sensor output with oscilloscope or multimeter in AC mode (should produce pulsating signal).
9. Verify motor windings resistance is balanced (4-6 ohms between any two terminals).
10. If sensor and motor test good but error persists, replace motor control unit (MCU) W
11. If F7E1 returns after MCU replacement, replace main control board W
12. After repair, run diagnostic spin test verifying motor reaches 800+ RPM during high-speed spin.
Still Not Working?

If the replacement part didn’t fix the issue, you may have a wiring problem or main board failure.
January 31, 2026
