Error Code: FAE5 / F10E5 Difficulty: Moderate
Problem: Indicates a leak has been detected, and the cycle has been canceled.
How to Fix FAE5 / F10E5 Error (Step-by-Step)
- Turn off the power to the dishwasher at the circuit breaker to ensure safety.
- Shut off the water supply valve, which is typically located under the kitchen sink.
- Place towels on the floor and carefully slide the dishwasher out from under the counter.
- Remove the lower front access panel(s) to get a view of the base pan.
- Use a sponge or towels to completely soak up all the water that has collected in the pan. The error is triggered by a sensor that detects this water.
- Carefully inspect hoses, the water inlet valve (model-specific part; confirm by full model number), and the pump assembly (model-specific part; confirm by full model number) for the source of the leak and replace the faulty part.
- Once the leak is repaired and the pan is dry, reconnect power and water and run a test cycle to check for leaks before sliding the unit back into place.
- Turn the appliance off, wait about 2 minutes, then turn it back on.
Amana Dishwasher Checks Before Replacing Parts
- Cut power at the breaker for at least one minute, then restore power and run a short cycle to see whether the same code or light pattern returns.
- Open the door and inspect the latch, strike, racks, spray arms, float, filter, and lower sump for anything that can interrupt the cycle or block water movement.
- Check the drain hose loop, sink knockout, disposer connection, and air gap if the symptom involves standing water, repeated draining, or a cycle that will not complete.
- Use the complete model number from the door or tub tag before ordering any pump, valve, latch, heater, sensor, or control-board category part.
- If the fault returns immediately after these checks, document the exact lights, beeps, and cycle stage; repeated electronic faults usually need meter testing before parts are replaced.
Recommended Parts to Check
Use these as symptom-based starting points, then confirm the exact fit with the full Amana dishwasher model number from the door or tub tag before ordering.
Amana dishwasher drain pump
Most likely when: water stays in the tub, draining sounds weak, or the cycle stops before completing.
Check first: filter, drain hose, disposer knockout, air gap, and the drain path.
Amana dishwasher water inlet valve
Most likely when: the tub does not fill, fills slowly, or stops early after the supply checks out.
Check first: shutoff valve, float, inlet screen, water pressure, and harness connection.
Amana dishwasher control board
Most likely when: lights stay stuck, buttons do not respond normally, or the fault returns after wiring and reset checks.
Check first: breaker reset, door switch signal, keypad response, visible board damage, and loose connectors.
Amana dishwasher door latch or switch
Most likely when: the cycle starts and stops, lights blink after closing, or symptoms change when the door is moved.
Check first: latch strike alignment, door seal pressure, connector fit, and switch continuity.
When It’s Better to Replace Than Repair
Dishwasher repairs can add up quickly when the pump, control, heater, or leak-related parts fail.
Confirm cabinet width, water line, drain routing, electrical connection, and panel style before ordering.
For repair parts, verify exact fit with the full dishwasher model number before buying; these links are general replacement-appliance shopping options.
- [OK]Drain pump or circulation pump failure
- [OK]Leaking tub, door, or float-switch issues
- [OK]Heater or control failures on an older unit
- [OK]Repeated poor washing or drying performance
Recommended Dishwasher Replacement Options
As an Amazon Associate, we earn from qualifying purchases.
Still Not Working?
If the error returns after the basic checks, stop and recheck the dishwasher model number, wiring connections, water supply, drain path, and any recently replaced part before buying another component.
