Error Code: F7E5 Difficulty: Hard
Problem: Indicates a shifter fault.
How to Fix F7E5 Error (Step-by-Step)
- Turn off the power to the dishwasher at the circuit breaker and shut off the hot water supply valve under the sink.
- To access the bottom of the unit, carefully slide the dishwasher out from under the countertop.
- Gently lay the dishwasher on its back on a towel or blanket to protect the floor and the unit.
- Locate the diverter motor, also known as a shifter or actuator, which is mounted on the side of the sump assembly at the bottom.
- Disconnect the wire harness attached to the motor, then remove the screws holding it in place.
- Install the new diverter motor (model-specific part; confirm by full model number), secure it with the mounting screws, and plug the wire harness back in.
- Carefully set the dishwasher upright, slide it back into place, reconnect the water and power, and run a test cycle.
- Turn the appliance off, wait about 2 minutes, then turn it back on.
Amana Dishwasher Checks Before Replacing Parts
- Cut power at the breaker for at least one minute, then restore power and run a short cycle to see whether the same code or light pattern returns.
- Open the door and inspect the latch, strike, racks, spray arms, float, filter, and lower sump for anything that can interrupt the cycle or block water movement.
- Check the drain hose loop, sink knockout, disposer connection, and air gap if the symptom involves standing water, repeated draining, or a cycle that will not complete.
- Use the complete model number from the door or tub tag before ordering any pump, valve, latch, heater, sensor, or control-board category part.
- If the fault returns immediately after these checks, document the exact lights, beeps, and cycle stage; repeated electronic faults usually need meter testing before parts are replaced.
Recommended Parts to Check
Use these as symptom-based starting points, then confirm the exact fit with the full Amana dishwasher model number from the door or tub tag before ordering.
Amana dishwasher drain pump
Most likely when: water stays in the tub, draining sounds weak, or the cycle stops before completing.
Check first: filter, drain hose, disposer knockout, air gap, and the drain path.
Amana dishwasher water inlet valve
Most likely when: the tub does not fill, fills slowly, or stops early after the supply checks out.
Check first: shutoff valve, float, inlet screen, water pressure, and harness connection.
Amana dishwasher control board
Most likely when: lights stay stuck, buttons do not respond normally, or the fault returns after wiring and reset checks.
Check first: breaker reset, door switch signal, keypad response, visible board damage, and loose connectors.
Amana dishwasher door latch or switch
Most likely when: the cycle starts and stops, lights blink after closing, or symptoms change when the door is moved.
Check first: latch strike alignment, door seal pressure, connector fit, and switch continuity.
When It’s Better to Replace Than Repair
Dishwasher repairs can add up quickly when the pump, control, heater, or leak-related parts fail.
Confirm cabinet width, water line, drain routing, electrical connection, and panel style before ordering.
For repair parts, verify exact fit with the full dishwasher model number before buying; these links are general replacement-appliance shopping options.
- [OK]Drain pump or circulation pump failure
- [OK]Leaking tub, door, or float-switch issues
- [OK]Heater or control failures on an older unit
- [OK]Repeated poor washing or drying performance
Recommended Dishwasher Replacement Options
As an Amazon Associate, we earn from qualifying purchases.
Still Not Working?
If the error returns after the basic checks, stop and recheck the dishwasher model number, wiring connections, water supply, drain path, and any recently replaced part before buying another component.
